Carports

Carports

CPQBCOMBID

300 x 500

Options

GM405Rain gutter flat roof1
2127Pole plate 12x128
2129Pole plate U 12x12 heavy8
2131Pole anchor H 12x12 heavy8

GM405

2127

2131

Dimensions

452,8
313
467,3
289
13,5
503,8
313
15,77
217
198

Properties

Type of construction: solid construction built with treated wood
Treatment of timber: class 3: against rot and insects, timber for outside use but without direct groundcontact
Walls: 26 mm thick spruce in QB profile, pressure impregnated
Roof cover: polyester corrugated sheet
Warranty: 5 years, see warranty conditions

Dimension on ground carport: 313 x 452,8 cm
Dimension inner carport: 289 x 467,3 cm
Surface inner carport: 13,50 m²
Dimension overall carport: 313 x 503,8 cm
Surface overall carport: 15,77 m²

Free Height : 198 cm
Total height: 217 cm
Weight: 700 kg
Packing WxDxH: 500 x 120 x 60 cm

Section of posts: 12 x 12 cm, to be anchored above ground. Anchors not included

Downloads


Mounting instructions
