Garage

Dimensions

Properties

Type of construction: garage with windproof timber corner joint
Treatment of timber: Pressure-impregnated class 3: protection against rot, mould and insects. With additional wax additive for temporary and limited water-repellency.
Walls: 28 mm thick pressure impregnated spruce
Roof: OSB3
Roof cover: EPDM
Rainwater evacuation: included (down to the ground)

Dimension on ground baseproduct: 510 x 300 cm
Surface on ground baseproduct: 15,3 m²
Dimension inner baseproduct: 504 x 294 cm
Surface inner baseproduct: 14,82 m²
Dimension overall baseproduct: 510 x 300 cm
Surface overall baseproduct: 15,3 m²
Minimal recommended size of concrete base: 300 x 510 cm

Height of sidewall: 215 cm
Height of ridge: 217 cm
Roof slope: 1 °
m² to be treated: 80 m²
Weight: 720 kg
Packing WxDxH: 510 x 120 x 70 cm

Doortype 1: DPQB01
Description door 1: double gate QB
Lock door 1: stainless steel ball latch with cylinder
Dimensions door 1 W x H: 2 x 114 x 189 cm
Daylight size door 1 W x H: 227 x 188 cm
Window type 1: HRQB2
Description window 1: window QB
Glazing window 1: transparent plexiglass
Daylight size window 1: 190 x 27 cm
