Logcabin

Dimensions

Properties

Type of construction: log cabin with windproof 3D connection
Ends of the boards: diamond
Walls: traditional log cabin style construction in 28 mm thick spruce from the high North
Roof: 15 mm thick spruce from the high North
Roof cover: shingles with optional choice of colour

Dimension on ground baseproduct: 505 x 295 cm
Surface on ground baseproduct: 14,9 m²
Dimension on ground extension: 367,2 x 295 cm
Surface on ground extension: 10,83 m²
Dimension inner baseproduct: 479,4 x 269,4 cm
Surface inner baseproduct: 12,92 m²
Dimension inner extension: 367,2 x 269,4 cm
Surface inner extension: 9,89 m²
Dimension overall baseproduct: 511 x 315 cm
Surface overall baseproduct: 16,1 m²
Dimension overall extension: 370 x 315 cm
Surface overall extension: 11,66 m²
Minimal recommended size of concrete base: 872,2 x 295 cm

Height of sidewall: 216 cm
Height of ridge: 318 cm
Roof slope: 36 °
m² to be treated: 150 m²
Packing WxDxH: 510 x 110 x 60 + 390 x 110 x 40 cm + 100 x 40 x 55 cm

Doortype 1: DDC01
Description door 1: double door Classic surface mounted
Glazing door 1: transparent glass 4 mm
Lock door 1: stainless steel latch with cylinder
Dimensions door 1 W x H: 145 x 189 cm
Daylight size door 1 W x H: 143 x 188 cm
Window type 1: EOR01L
Description window 1: single opening window lying type 1
Glazing window 1: transparent glass 4 mm
Daylight size window 1: 73 x 60 cm
Window type 2: EOR01L
Description window 2: single opening window lying type 1
Glazing window 2: transparent glass 4 mm
Daylight size window 2: 73 x 60 cm
