Logcabin

Dimensions

Properties

Type of construction: log cabin with windproof 3D connection
Ends of the boards: diamond
Treatment of timber: Pressure-impregnated class 3: protection against rot, mould and insects. With additional wax additive for temporary and limited water-repellency.
Walls: traditional log cabin style construction in 28 mm thick spruce from the high North
Roof: 15 mm thick spruce from the high North
Roof cover: shingles with optional choice of colour

Dimension on ground baseproduct: 355 x 355 cm
Surface on ground baseproduct: 12,6 m²
Dimension on ground extension: 355 x 292,2 cm
Surface on ground extension: 10,37 m²
Dimension inner baseproduct: 329,4 x 329,4 cm
Surface inner baseproduct: 10,85 m²
Dimension inner extension: 329,4 x 292,2 cm
Surface inner extension: 9,63 m²
Dimension overall baseproduct: 375 x 358 cm
Surface overall baseproduct: 13,43 m²
Dimension overall extension: 375 x 295 cm
Surface overall extension: 11,06 m²
Minimal recommended size of concrete base: 355 x 647,2 cm

Height of sidewall: 202 cm
Height of ridge: 341 cm
Roof slope: 40 °
m² to be treated: 125 m²
Packing WxDxH: 360 x 110 x 60 + 300 x 110 x 40 cm + 100 x 40 x 55 cm

Doortype 1: DDC03
Description door 1: surface mounted double door Heritage
Lock door 1: stainless steel latch with cylinder
Dimensions door 1 W x H: 145 x 189 cm
Daylight size door 1 W x H: 143 x 188 cm
Window type 1: EVR03
Description window 1: single closed window Heritage
Glazing window 1: transparent plexiglass
Daylight size window 1: 73 x 60 cm
